Worm shaped extruding dehydrator system

Spiral extrusion dehydrator is the latest research achievement in the world today. It overcomes the shortcomings of various traditional filters, integrates the advantages of various traditional dehydrators, adapts to different processing capacity and modular series of system products. The product has simple structure, full sealing, full intelligence, low energy consumption, no noise, low maintenance and maintenance, and very little backwash water. With the advantages of less floor space, we provide customers with high quality dehydration (filtration, solid-liquid separation) solutions.

The advantages of worm extruding dehydrator are:

A, low energy consumption: YS1200-II, high output, configuration of motor power 5.5 kW, actual operating current 3-5A, so energy saving.

B. Noise-free: because the speed of the equipment is very slow, only 0.5-2r/min, basically no noise, unlike the centrifuge high speed brings a lot of noise.

C. Complete sealing: Traditional equipment is open to operation, the environment is bad, the equipment sealing structure, the system through the module seamless combination connection design, odor and harmful sludge particles can not escape, to ensure a good working environment.

D. Backwash water is very few: metal filter is not easy to plug, through the internal settings of continuous regeneration, can not be washed, to achieve the same treatment effect, water finger clearance spraying and end cleaning, saving water resources.

E, all intelligent: automatic intelligent control PLC, the traditional equipment on, off, adjust, it is difficult to organic combination, the system combination of initial settings, normal operation as long as the start and stop, easy to operate, can reduce the operator, improve work efficiency, especially the module placed mobile card, remote support.

F. Maintenance and repair province: because the equipment is very slow, the internal structure is all stainless steel, corrosion resistance, so there is no wear and tear parts, no need to replace the filter cloth, filter continuous work for 2-5 years generally do not need to repair, just the usual speed reducer refueling.

G, less floor space: the system is round design, factory production integration modular combination, integral hoisting in place, do not need special machine foot fixed, avoid tedious installation, beautiful, economical, simple and convenient.

H, wide applicability: because of its many advantages, it can be extended to other areas, municipal wastewater treatment sludge, municipal wastewater activated sludge, paper industry, brewing industry, pharmaceutical industry, biofilter sludge, septic tank, cinder, slag, slaughterhouse, livestock waste, chemical dewatering.

I. Large capacity: Suitable for large-scale sewage treatment plants. The parameters are 2 module specifications. Customers can choose 2-6 module combinations according to their needs.

选型参数：
